Honda announces the 2025 Pioneer 520... Where is the 500?

Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,500
67,170
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
Today, Honda officially announced the return of the Pioneer 520 SxS for 2025.
Official info is below.

Where is the 500?
Was 2023 the final year for the Pioneer 500?
Honda is already launching the 2025 Pioneer 520 models; however, the 2024 Pioneer 500 has yet to be released.
Could this be a sign it's no longer in production? We think so.


2025 Pioneer 520 Acc Sales Guide v2 1


---------------------------
June 18, 2024
Honda's Pioneer 520 is the ideal side-by-side for anyone looking for a hardworking rec/utility vehicle that's also fun to operate, and for the 2025 model year, it's offered in three new colors, including TrueTimber Atera Camo®, thanks to an extensive, powersports-exclusive brand partnership between Honda and the popular camouflage brand. With chassis dimensions compact enough to fit into the bed of most full-size pick-up trucks, it's also able to navigate public ATV trails. This rugged little side-by-side is powered by a torquey 518cc engine that can scramble up the most challenging terrain, while its independent front and rear suspension make for a comfortable ride with plenty of control. Perks include a dump bed that accommodates up to 450 pounds and that can be augmented with Honda Pro-ConnnectTM accessories. Designed and manufactured in the U.S., the Pioneer 520 is the embodiment of tough, reliable fun.
CHASSIS / SUSPENSION
A 450-pound capacity dump bed provides users with greater utility. Interior bed dimensions are 25.9 inches long, 38.7 inches wide and 9.8 inches high, and Honda has packed in a lot of functionality, incorporating recess rings for 5-gallon buckets, ridges to help position milk crates, slots to hold a wood divider and five D-rings for tie-downs. There are even cup-holder rings in the gate.​
In addition, the Pioneer 520 is Pro-Connect compatible, with 10 latches located around the bed's perimeter, to easily accept nine Pro-Connect accessories—including cargo boxes, bed rails and chainsaw mounts—without the need for tools, improving flexibility and convenience. A total of 41 accessories are offered, some of which are interchangeable with other Pro-Connect compatible Honda side-by-sides and ATVs. Examples include a bed rack, cargo boxes, a chainsaw mount and more.
The 50-inch vehicle width is exclusive to Honda in this class, a signature design element that has proven popular with customers. The compact size means the Pioneer 520 can be ridden on public ATV trails everywhere, maximizing the vehicle's versatility. It can even be loaded into the bed of a full-sized pickup truck for transport.
Overall length is 105.0 inches, and wheelbase is 73.0 inches. Front and rear suspension travel are 5.8 and 5.9 inches, respectively, and ground clearance is 8.5 inches, great for tackling uneven or challenging terrain.
Honda's engineers ensured shocks are designed for increased comfort and control. Front and rear suspension are modern independent double-wishbone designs; the rear suspension has adjustable preload to tailor the ride height to match loads.
All four rims have 12-inch diameters and are shod with 24-inch-diameter all-terrain tires—24x8-12 up front and 24x10-12 in the back. This setup makes for a good balance between traction, easy steering and good maneuverability in tight quarters. The front brakes comprise dual hydraulic calipers with 200mm discs, while the rear brake is a single hydraulic caliper with a 170mm disc—a combination that provides substantial braking power.
ENGINE / DRIVETRAIN
The Pioneer 520 is powered by the proven, fuel-injected four-stroke 518cc engine tuned for side-by-side application. The largest engine in its class, the power plant has bore-and-stroke figures of 96.0mm and 75.3mm. As a result, it offers ample low-to-midrange power and torque, making it great for tackling chores or scrambling up trails while exploring challenging terrain. Power is fed directly to front and rear driveshafts, with no belt drive to maintain. Once again, it is mounted longitudinally in the chassis, an arrangement that allows direct driveshaft alignment to front and rear wheels for maximum drivetrain efficiency.​
At the same time, ease of use is prioritized. The air cleaner is readily accessible, as is the battery box, by lifting the bed. Two drive modes—two- and four-wheel drive—are selectable on-the-fly via an easy-to-reach, dash-mounted knob. The five-speed automatic transmission with reverse takes the hassle out of gear selection. The manual mode, operated with paddle shifters on the steering column, gives the user shifting control when conditions warrant. The Pioneer 520's shift mapping is tuned to upshift at lower engine speeds, improving shift rhythm. Calibration is set to optimize shift shock, and manually overriding automatic mode is possible through a wider rpm range.
Towing capacity is 1,000 pounds.

24 Honda Pioneer 520 Hero Red LHP 24 Honda Pioneer 520 Hero Red LR34 24 Honda Pioneer 520 Hero Red rear 24 Honda Pioneer 520 Hero Red RF34 24 Honda Pioneer 520 Hero Red RHP 24 Honda Pioneer 520 Hero Red RR34 24 Honda Pioneer 520 Hero Red top 25 Honda Pioneer 520 Hero Red accessorized 25 Honda Pioneer 520 Slate Gray front 25 Honda Pioneer 520 Slate Gray LF34 25 Honda Pioneer 520 Slate Gray LHP 25 Honda Pioneer 520 Slate Gray LR34 25 Honda Pioneer 520 Slate Gray rear 25 Honda Pioneer 520 Slate Gray RF34 25 Honda Pioneer 520 Slate Gray RR34 25 Honda Pioneer 520 Slate Gray top 25 Honda Pioneer 520 TrueTimber Atera Camo accessorized 25 Honda Pioneer 520 TrueTimber Atera Camo front 25 Honda Pioneer 520 TrueTimber Atera Camo LF34 25 Honda Pioneer 520 TrueTimber Atera Camo LHP 25 Honda Pioneer 520 TrueTimber Atera Camo LR34 25 Honda Pioneer 520 TrueTimber Atera Camo rear 25 Honda Pioneer 520 TrueTimber Atera Camo RF34 25 Honda Pioneer 520 TrueTimber Atera Camo RR34 25 Honda Pioneer 520 TrueTimber Atera Camo top 24 Honda Pioneer 520 Hero Red front 25 Honda Pioneer 520 Slate Gray accessorized 25 Honda Pioneer 520 TrueTimber Atera Camo RHP

advertisement
lee

lee

Village Idiot
Lifetime Member
Club Contributor
Apr 4, 2013
2,401
13,601
113
Springfield Ohio
Ownership

  1. 500
Was 2023 the final year for the Pioneer 500?

Honda dropping the p500 is just bulls***.
It's the same old collage boy thinking he knows better just because daddy paid for him to go party for 4 or 5 years.
These types of bad decisions are totally out of touch with the reality of 50" trail riding in a vehicle with practical utility.
If honda is not willing to think outside the box and be different I might as well get that Canned Ham Maverick Trail.

futzin

futzin

Well-Known Member
Lifetime Member
Sep 10, 2019
4,286
31,760
113
Kentucky
Ownership

  1. 500

  2. 520
The offerings from Lowes, TSC, Home Depot etc will leap-frog Honda before long.

Just. Sad.

The revenue is there. Everyone collecting it except Honda. Skewed thinking.

  • Haha
  • Like
Reactions: TxDoc and NTCPrezJB
