  1. 700-4
Hey fellas! I have read through multiple posts (including the write up by @Hondasxs) and different forums regarding the reverse override but I was wondering of there was anymore information on wiring the override to my rocker switch on the dash. I would say my electrical knowledge it average at best.

Are there any write ups on this that I glanced over on accident? If not, does anyone have any info from personal experience!

Thanks!

Lerz

  • Like
Reactions: Black325xi
Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,511
67,231
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
Yes. It's easy, but confusing.
You will need a ON/ON switch.
A ON/off/ON will also work but leaves you confused when you accidentally leave it in off.

I'll have to review my notes on this tonight and I'll hit you back.


Sent from my SM-G955U using Tapatalk

JaLerz

JaLerz

Member
Dec 1, 2018
40
31
18
NorCal
Ownership

  1. 700-4
Yes. It's easy, but confusing.
You will need a ON/ON switch.
A ON/off/ON will also work but leaves you confused when you accidentally leave it in off.

I'll have to review my notes on this tonight and I'll hit you back.


Sent from my SM-G955U using Tapatalk
Thanks for getting back to me.

I have a standard on/off switch, not quite sure what an ON/ON switch is...

Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,511
67,231
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
Thanks for getting back to me.

I have a standard on/off switch, not quite sure what an ON/ON switch is...
On/off will not work with this design.

Sent from my SM-G955U using Tapatalk

Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,511
67,231
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
The switch.
Switch has 3 points as a on/on
We will call then points 1, 2, and 3.
2 being input and controls 1 and 3 as outputs.

The R wire is the only one that needs to be cut.

The D wire is only tapped to be fed from the R when switched. It's ok to back feed as it dies.
Use a positap to test workings then soldier it for solid connection.

Hers is how to do it.
Run the R from wire harness side to point 1.
Run gear position side to point 2.
Point 3 is ran and tapped to the D wire.








Sent from my SM-G955U using Tapatalk

Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,511
67,231
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
JaLerz

JaLerz

Member
Dec 1, 2018
40
31
18
NorCal
Ownership

  1. 700-4
Here is an on off on switch.
https://www.amazon.com/Bandc-Marine-Rocker-Switch-Waterproof/dp/B00EBR0U5I/?tag=sxsweb24-20


Here is a On/On body only.
ON-ON | rocker switch | ind lamp | three way rocker switch

There is not many options out there for on/on.
Im searching my self for some currently.

Sent from my SM-G955U using Tapatalk
Does it have to be a 7 pin on/off/on? As petty as it sounds, I'd like to find one that matches my current switches.

20181223 113709

Hondasxs

Hondasxs

Club Founder
Staff member
Lifetime Member
Supporting Member
Feb 13, 2013
18,511
67,231
113
Charlotte, NC
HondaSxS.com
Ownership

  1. 1000-5

  2. Talon R
Does it have to be a 7 pin on/off/on? As petty as it sounds, I'd like to find one that matches my current switches.

View attachment 99597
I know.. that's my trouble too. Lol.

No. A 7 pin is not required. That's for illumination features if wanted. Which complicates things more.

A basic unlighted on/on or on/off/on will be 3 pin.

Sent from my SM-G955U using Tapatalk

advertisement
JaLerz

JaLerz

Member
Dec 1, 2018
40
31
18
NorCal
Ownership

  1. 700-4
I understand now. Thank you.

I am sure I will have some questions when I get home from work in a few days and start working on it
