P1000m5 2019 P1K5 Black Widow!

ProudDadOf5 submitted a new Garage Item:

2019 Pioneer 1000-5 Deluxe

It’s a 2019 Pioneer 1000-5 Deluxe. All blacked out. We absolutely love it‼️

Read more about this showcase item here...



[ProudDadOf5]

how did you do the winch?

Sh**, where to start! JK it was easy once you figure out where you want to run your wires. I ordered the Viper Elite Widespool Winch for from the Honda SXS store with the mounting kit. I already had a winch flush mount rocker switch kit to replace the one that comes with the winch witch Is green and all my rockers are blue. @Hondasxs was a huge help in choosing everything I needed!!

1. You have to remove the bumper from the plastic using a Allen wrench then from the frame with 2 bolts located at the bottom and 4 bolts located in the middle.

2. Then you attach the winch to the mounting plate. The directions tell you to mount it upside down but I am mounted mine right side up where are you can engage the free spool gear on the driver side. I did not have to cut a single thing it fit behind the stock bumper with plenty of room.

3. You have to mount the winch with the plate attached to the tube subframe. After I mounted this I went ahead and loosely hooked my wires up to the winch.

4. Once you have a located where you would like to put the wireless relay box and the solenoid, you’re ready to wire up. I located my wireless remote on top of the cubby box (strong 3M double sided sticky tape) and solenoid to the left of air cleaner. I still have all the room to run dual batteries with the kits sold from the club store if I go that route.

Here is a pic of my busbar situation for all accessories on driver side.

Last but not least here’s a picture of the end result. Tried to keep it as clean as possible!!

Just waiting on my blank covers to come in.

The flush mount winch rocker works the same direction as the factory would have. In on top and out on bottom.



[ProudDadOf5]

I was willing to drive 5-6hours one way but every time I found one and called on it, it was the same story. GONE!! Lol

That sucks bro. I keep hearing there hard to find. If you were willing to put in that much effort I sure wish you could’ve got one.



[Russ989]

Sh**, where to start! JK it was easy once you figure out where you want to run your wires. I ordered the Viper Elite Widespool Winch for from the Honda SXS store with the mounting kit. I already had a winch flush mount rocker switch kit to replace the one that comes with the winch witch Is green and all my rockers are blue.

1. You have to remove the bumper from the plastic using a Allen wrench then from the frame with 2 bolts located at the bottom and 4 bolts located in the middle.

View attachment 174582

View attachment 174583

2. Then you attach the winch to the mounting plate. The directions tell you to mount it upside down but I am mounted mine right side up where are you can engage the free spool gear on the driver side. I did not have to cut a single thing it fit behind the stock bumper with plenty of room.

View attachment 174586

View attachment 174587

3. You have to mount the winch with the plate attached to the tube subframe. After I mounted this I went ahead and loosely hooked my wires up to the winch.

View attachment 174588

4. Once you have a located where you would like to put the wireless relay box and the solenoid, you’re ready to wire up. I located my wireless remote on top of the cubby box and solenoid to the left of air cleaner. I still have all the room to run dual batteries with the kits sold from the club store if I go that route.

View attachment 174592

View attachment 174593

Here is a pic of my busbar situation for all accessories on driver side.

View attachment 174596

Last but not least here’s a picture of the end result. Tried to keep it as clean as possible!!

View attachment 174595

Just waiting on my blank covers to come in.

View attachment 174598

The flush mount winch rocker works the same direction as the factory would have. In on top and out on bottom.

Looking good!



[Russ989]

That sucks bro. I keep hearing there hard to find. If you were willing to put in that much effort I sure wish you could’ve got one.

Me too.



[Russ989]

Thanks a lot for the info, I need a winch!

They are handy! These pics are from the takeover last year.



[ProudDadOf5]

Looking good!

Very much appreciated. Many man hours installing everything just the kids & myself. Kids helped hand me tools as I explain what I’m doing at each step. Nothing beats knowledge and gets their head out of that damn game system.



[Isaiah]

They are handy! These pics are from the takeover last year.

View attachment 174601 View attachment 174602

I cant wait for the takeover, this will be my first time!



[ProudDadOf5]

Thanks a lot for the info, I need a winch!

You’re most certainly welcome. Anything for a fellow club member. Yep, they’re nice to have. Sucks getting stuck without one!!



[Russ989]

I cant wait for the takeover, this will be my first time!

You’ll love it. We did the Takeover and Windrock last year.



[Isaiah]

Very much appreciated. Many man hours installing everything just the kids & myself. Kids helped hand me tools as I explain what I’m doing at each step. Nothing beats knowledge and gets their head out of that damn game system.

You’re most certainly welcome. Anything for a fellow club member. Yep, they’re nice to have. Sucks getting stuck without one!!

I know, I have a winch on my rubicon I use it a lot



[Russ989]

We went to the prison when we went to Windrock in October, it was a blast!



[Isaiah]

You’ll love it. We did the Takeover and Windrock last year.

hope to meet you



[ProudDadOf5]

We went to the prison when we went to Windrock in October, it was a blast!

View attachment 174604 View attachment 174605 View attachment 174606

Damn Russ, prison was the result. Sounds like an awesome time!! I’ll bring some shine down..



[Russ989]

Damn Russ, prison was the result. Sounds like a damn good time!!

It was!



[Russ989]

hope to meet you

Likewise



[Isaiah]

We went to the prison when we went to Windrock in October, it was a blast!

View attachment 174604 View attachment 174605 View attachment 174606

Where is the prison?



[ProudDadOf5]

Likewise

Same here fellas!!



[Russ989]

Where is the prison?

Tours — Historic Brushy Mountain State Penitentiary



[Isaiah]

Tours — Historic Brushy Mountain State Penitentiary

I will have to check that out!



[Isaiah]

Do you know how far is it from RRB?
