Those look great. Do you have a link to the build? I’m assuming usual MDF ring on stilts, then covered and fiberglassed?
No I kinda just winged it with ply wood and fiberglass nothing to it really just to do it made both in 30 min

toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
So, I'm back from vacation and ready to work of stuff. I have the roof where I'm happy and started painting it this afternoon.

This morning I started the install on the bump seat. It came nicely packaged and installed in about 1 hour at most.

123


5E553C0B 6C3C 498D AFEB AA2D7AD60E1D

Last edited:
toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
I didn’t have it pushed back far enough yesterday when I tried to install it. The bracket was correct. I didn’t realize when they said “pry” it better the seats, that I would have to climb in the machine and feel like I was going to break the seats getting it in between. But, I got it. ;)

8E6126B3 3655 41B8 A0D6 5C803D88CDAE

F481C7B1 E285 4F96 AA42 9F8B173CDA78


The machine goes in low now.


7C62AFE5 372A 4A93 8BE1 DFB111489678

Last edited:
toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
Top view.

EEAFF491 0421 4EE1 9472 C84FF5563D50


Here is my 50lb 6 year old sitting in it before I pushed it between the seats. Should be good for at least 2 years with the lower cage on the machine.

5D1F709F A6BB 4C8F 867D B2161FB5883B

Last edited:
sspeederr

sspeederr

Well-Known Member
Lifetime Member
Supporting Member
May 10, 2020
391
661
93
24701
Ownership

  1. Other Brand

  2. Talon R
Top view of how far it sticks over the seats.

View attachment 257957
i have the same seat and mine fits between the factory seats and i am able the get in low gear no problem
it looks like your bracket maybe on backwards try flipping the bump seat bracket and put it between both seats i have about 2 in clearance above the cup holders your looks like its sitting on them.

toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
I was poking around today looking for ways to spend more money on this machine, and found out it already has mud gaurds in front of the rear tires already. I just need to grab a few pushpins, or zip ties.



136

  • Like
Reactions: lowranger
toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
I got my roof on today. It's 1/8' aluminum. Hopefully the black paint holds up. I used some spacer clamps on the middle bar to give it a little arch. I also used some 1/2" gasket by the bolts to try to stop rattling.

131


132


133

advertisement
toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
It didn’t fit quite right when I got home. Over bent the angles. It’s about 1-3/4” too narrow. 🤔

I think I’ll cut some slits in the bends to open them back up a little and just weld it tomorrow. Your not a good welder until you’re a good grinder!

Im trying to decide if I want to do a swing away hinge, or make it drop in with pins. I don’t really think I’ll be opening it that much. I’ll use the 1000-5 if I need a bed.

Overall it actually fits really close for my crappy cardboard template and 45 minutes worth of work so far!

toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
I’m not sure if I’ll do a spare tire mount or not. It does fit inside the bed right now. I haven’t needed a spare tire on any of my trail rides for the last 20 years. I just carry a plug kit and I’ve only used it once on someone else’s machine. But, I’ve heard the talon needs some rear weight.

  • Like
Reactions: CID and Mudwing
toddvdh

toddvdh

Well-Known Member
Lifetime Member
Jun 23, 2020
1,108
7,331
113
Green Bay, WI
Ownership

  1. 1000-5

  2. Talon X
Well, I decided to go with a drop in type design. I put 4 clamps on my cage and put 4 pins on the gate. I’ll secure it down with a couple bungee cords because I don’t think I’ll be taking it off and on very often. It stays where it is without the bungees and doesn’t rattle, but I figure they are cheap insurance. I’ll get a pic on the machine this weekend.
